RXM4AB2FD – Harmony,6 A, 2 CO, with lockable, 220 VDC

Main
Range of product
Harmony Electromechanical Relays
Series name
Miniature
Product or component type
Plug-in relay
Device short name
RXM
Contacts type and composition
4 C/O
[Uc] control circuit voltage
110 V DC
Status LED
With
Control type
Lockable test button
Utilisation coefficient
20 %
Complementary
Shape of pin
Flat
[Ui] rated insulation voltage
250 V conforming to IEC
300 V conforming to CSA
300 V conforming to UL
[Uimp] rated impulse withstand voltage
2.5 kV during 1.2/50 µs
Contacts material
AgNi
[Ie] rated operational current
3 A at 28 V (DC) NC conforming to IEC
3 A at 250 V (AC) NC conforming to IEC
6 A at 28 V (DC) NO conforming to IEC
6 A at 250 V (AC) NO conforming to IEC
6 A at 277 V (AC) conforming to UL
8 A at 30 V (DC) conforming to UL
Continuous output current
5 A
Maximum switching voltage
250 V conforming to IEC
resistive rated load
6 A at 250 V AC
6 A at 28 V DC
Maximum switching capacity
1500 VA/168 W
Minimum switching capacity
170 mW at 10 mA, 17 V
Operating rate
<= 1200 cycles/hour under load
<= 18000 cycles/hour no-load
Mechanical durability
10000000 cycles
Electrical durability
100000 cycles for resistive load
