SCHNEIDER – C63F42D630 – MCCB 4P, 250-630A, 36KA MIC 2.3 NSX630F

Range ComPacT new generation Product name ComPacT NSX new generation Device short name NSX630F Product or component type Circuit breaker Device application Distribution Poles description 4P Protected poles description 4D 3D + N/2 3D Neutral position Left [In] rated current 630 A at 40 °C [Ue] rated operational voltage 690 V AC 50/60 Hz Network type AC Network frequency 50/60 Hz Suitability for isolation Yes conforming to EN/IEC 60947-2 Utilisation category Category A [Icu] rated ultimate short-circuit breaking capacity 40 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 36 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 30 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 25 kA Icu at 500 V AC 50/60 Hz conforming to IEC 60947-2 20 kA Icu at 525 V AC 50/60 Hz conforming to IEC 60947-2 10 kA Icu at 660/690 V AC 50/60 Hz conforming to IEC 60947-2 20 kA at 600 V AC 50/60 Hz conforming to UL 508 Performance level F 36 kA 415 V AC Trip unit name Micrologic 2.3 Trip unit technology Electronic Trip unit protection functions LSoI control type Toggle Circuit breaker mounting mode Fixed
